Extraction Systems for Metalworking
Safely capture welding fumes, metal dust, and metal chips with mobile and centralized extraction solutions for clean air, improved workplace safety, and reliable production processes.
Extraction Technology for Welding Fumes, Metal Dust, and Metal Chips in Metalworking
A high-performance extraction system for metalworking helps capture emissions directly at the source, keep work areas clean, and protect employees effectively. At the same time, application-specific extraction technology for metal dust and welding fumes supports compliance with occupational health and safety requirements, reduces cleaning effort, and improves process reliability across production.
For more than 35 years, AL-KO Extraction Technology has been developing customized extraction solutions for the metal industry – from mobile units for individual workstations to centralized filtration systems for complex production environments.
Capture welding fumes directly at the source
Reliably collect metal dust, grinding dust, and metal chips
Mobile and centralized extraction systems for metalworking
Improved workplace safety, clean air, and reliable production processes
Why Metalworking Companies Choose AL-KO Extraction Technology
Individual planning: Tailored solutions for processes, machines, and production environments in metalworking.
High process reliability: Reliable capture of welding fumes, metal dust, and metal chips for clean, stable operations.
Energy-efficient operation: Optimized systems for long-term cost-efficient performance.
Future-ready solution: Scalable extraction systems for growing production requirements and changing manufacturing processes.
Everything from a single source: From analysis and consultation to planning, system design, implementation, and commissioning
The Right Extraction Solution for Every Metalworking Requirement
Depending on the application, different product solutions come into focus: welding fume filters for direct source capture at the workstation, dust collectors for metal dust and grinding dust, centralized filtration systems for larger production areas, and industrial vacuums for metal chips and flexible applications.
How Can We Support Your Project?
Get Free Expert Advice:
Consultant on site
You can find your personal contact person via your ZIP code
AL-KO THERM GMBH
Hauptstraße 248–250
89343 Jettingen-Scheppach
Germany
+49 8225 39-2412
–
et_contact@alko-air.com
Frequently Asked Questions (FAQ) About Extraction Systems in Metalworking
How can welding fumes be extracted effectively?
Welding fumes are captured most effectively directly at the source, for example with extraction arms, capture hoods, or integrated extraction solutions at the workstation. This helps prevent emissions from spreading throughout the facility. Specialized welding fume filters are used for filtration.
When welding unalloyed or low-alloyed steels, standard filter solutions are often sufficient. For high-alloy materials, such as chromium-nickel steels, stricter requirements apply to filtration performance and system design. If the technical and regulatory requirements are met, optional air recirculation can also support energy savings. For multiple welding stations, centralized, modular filtration systems offer clear advantages.
How can metal dust be extracted safely?
Depending on the material and particle size, metal dust can be combustible or explosive. That is why extraction technology in metalworking must be precisely matched to the specific application. Important criteria include dust type, explosion class, Ex zoning, and the requirements of the ATEX directives.
For materials such as aluminum, only appropriately certified extraction systems may be used. Grounding and equipotential bonding help reduce the risk of electrostatic charging as a potential ignition source. Depending on the material, separate collection may also be required to prevent mixing and unwanted reactions. Additional protective measures such as rupture discs, explosion suppression, or spark extinguishing systems further increase system safety. Regular cleaning is equally important to minimize dust buildup and the associated risks.
Which solution is suitable for extracting metal chips?
Metal chips are generated primarily during machining processes such as turning, milling, or sawing. To capture them reliably, extraction systems must be robust and high performing, with the ability to safely collect larger or heavier particles as well.
For individual machines and small to medium extraction volumes, compact dust collectors or machine-mounted solutions are well suited. In larger production environments with multiple extraction points, centralized filtration systems are often the better choice. Powerful industrial vacuums are ideal for cleaning floors, machines, and work areas after production. This allows deposited metal chips to be removed safely and efficiently.
When does a centralized extraction system make sense?
A centralized extraction system is especially useful when multiple machines or workstations in metalworking need to be connected at the same time. Compared with many stand-alone units, centralized systems are often more cost-effective, more space-efficient, and easier to maintain. Filter monitoring and overall system control can also be managed more efficiently from one central location.
In addition, centralized extraction systems offer high scalability when production capacity grows, or additional extraction points need to be integrated. Further benefits include improved energy efficiency, noise reduction, and the potential integration of heat recovery. If low noise exposure is a priority, a properly insulated centralized system installed outside the production hall is recommended.
Which extraction technology is suitable for grinding and milling processes?
Grinding generates fine grinding dust or metal dust, which may also be explosive depending on the material. Milling, by contrast, tends to produce fine to coarse metal chips. As a result, the extraction technology must always be matched to particle size, material type, and process requirements.
For multiple workstations, a centralized, modular filtration system can be an efficient solution. During the planning phase, it should also be assessed whether oil mist and emulsion mist separation for coolants and lubricants is additionally required at turning, grinding, and milling machines. The result is an extraction system designed to meet the demands of modern metalworking in a way that supports both process reliability and cost-efficient operation.
Why is AL-KO Extraction Technology the right partner for metalworking?
AL-KO Extraction Technology offers high-performance extraction systems for a wide range of metalworking applications, from welding fumes and metal dust to metal chips. What matters is not only the reliable capture of fumes, dust, and chips, but also a holistic approach to safety, energy efficiency, and scalability. The result is customized extraction solutions that can be precisely aligned with processes, materials, and operational requirements.
