Extraction Technology
AL-KO JET STREAM Industrial Vacuum Cleaners
Industrial vacuum cleaners of the AL-KO JET STREAM series are ideal for vacuuming accumulations of dust and swarf that occur in every production plant. The models with a side channel compressor are also suitable for direct vacuuming of machines and fixtures in continuous operation. The JET STREAM series offers the right device for every application.
AL-KO quality
Receive consultation in person
Operating principle
AL-KO JET STREAM vacuums are more than just conventional industrial vacuum cleaners. They are optimized for use in industrial and skilled trade applications. High-performance vacuum units – including turbine, side channel compressor or piston compressor versions – ensure maximum vacuuming power. A cleanable permanent filter removes swarf and dust from the vacuumed air. Depending on the version, filter cleaning takes place manually or automatically via an integrated cleaning system. Large-volume, movable collecting containers facilitate removal of the vacuumed material. Compatible vacuum accessories ensure fast and effective use in every type of application.
Your benefits
- Choose the right vacuum for your application from a large selection of devices – from compact AC vacuums to stationary central units
- Maintenance-free components with high suction power
- Cleanable permanent filter for low operating costs
- Low operating noise level
- Ergonomic design
- Versions for dry vacuuming, explosive ATEX Zone 22, and for vacuuming emulsions and liquids
- Compatible vacuum accessories for optimal efficiency
- Also available as central dust vacuuming units with pipe system
Applications
- Cleaning extraction in skilled traded and industrial enterprises
- Vacuuming of dust and swarf accumulations as well as emulsions and liquids
- Direct vacuuming on machines and fixtures is possible
- The right device for all types of materials, such as wood, metal, mineral dusts and plastic
- Single extractors and central extractors for connection to a pipeline system with multiple extraction points
Options & variants
- Different main filter materials for the particular application
- Additional H14 absolute filter for hazardous dusts
- Extensive accessories – separately or as a set
- Pipeline material for connection of multiple extraction points
Technical data
JET STREAM industrial vacuum cleaners
| JET STREAM | M | 202 DS M | 4533 M | 4535 M | DM 3 M | ZRF 75 M | DG 70 EXP M | DM 40 Oil |
|---|---|---|---|---|---|---|---|---|
| Suction nozzle Ø in mm | 35 | 50 | 80 | 80 | 80 | 80 | 80 | 80 |
| Max. airflow in m3/h | 150 | 360 | 300 | 450 | 540 | 370 | 530 | 540 |
| Max. vacuum in Pa. | 22,000 | 25,000 | 26,000 | 32,000 | 25,000 | 30,000 | 36,000 | 25,000 |
| Motor rating in kW | 1.2 | 2.3 | 2.2 | 4 | 3.45 | 3 | 5.5 | 3.45 |
| Filter area m2 | 0.6 | 3 | 2 | 2 | 3 | 3 | 3 | 0 |
| Sound pressure level dB(A) | 67 | 76 | 69 | 69 | 76 | 75 | 72 | 76 |
| Dimensions (L x W x H) in mm | 520 x 380 x 695 | 590 x 480 x 1,100 | 930 x 580 x 1,160 | 930 x 580 x 1,160 | 770 x 660 x 1,500 | 790 x 660 x 1,700 | 660 x 1.180 x 1,450 | 670 x 660 x 1,250 |
JET STREAM ATEX Zone 22 industrial vacuum cleaners
| JET STREAM | 202 BL M Z22 | 4533 M /22 | 4535 M Z22 | ZFR 75 M Z22 | DG 70 EXP M Z22 |
|---|---|---|---|---|---|
| Suction nozzle Ø in mm | 50 | 80 | 80 | 80 | 80 |
| Max. airflow in m3/h | 215 | 300 | 450 | 370 | 530 |
| Max. vacuum in Pa. | 22,000 | 26,000 | 32,000 | 30,000 | 36,000 |
| Motor rating in kW | 1.1 | 2.2 | 4 | 3 | 5.5 |
| Filter area m2 | 3 | 2 | 2 | 3 | 3 |
| Sound pressure level dB(A) | 74 | 69 | 69 | 75 | 72 |
| Dimensions (L x W x H) in mm | 570 x 480 x 1,080 | 930 x 580 x 1,160 | 930 x 580 x 1,160 | 790 x 660 x 1,700 | 660 x 1,180 x 1,450 |
All values are approximate and refer to the basic version; subject to technical modifications
